The UAP-200-2 Addressable Fire Alarm Control Panel uses unique protocol for loop communication. It supports 2 loops, 240 devices, and up to 16 control panels can be networked. It provides sturdy and dependable solutions for operating in difficult conditions.

The UAP-200-2 has an LCD graphic display that enables configuring device's settings and to seamlessly interpret faulty and alarm alerts. The built-in LAN network connection of the UAP-200-2 enables local or remote configuration and monitoring using the configuration software and monitoring software. The UAP-200-400 Fire Alarm Panels are manufactured in accordance with the European standards and are EN54-2 and EN54-4 certified.

FEATURES & BENEFITS

✓ EN 54-2 and EN 54-4 Certified

✓ User Friendly

✓ 2 loop capability is supported

✓ Each loop may support up to 240 devices and up to 480 devices in a single panel

✓ Up to 72 zone support

✓ Cable lengths of up to 2.5 kilometers per loop

✓ The UNC-01 Network Module can connect up to 16 control panels via RS-485

✓ The network can support up to 7.680 devices and 1.152 zones (Utilizing an optional UNC-01 Network Module)

✓ User-friendly interface and intuitive 240*64 large LCD digital display

✓ Customize the display with your company's logo, contact information, photos, and more

✓ Using a peer-to-peer communication network, all panels have the same level of accessibility and command transmission

✓ The Programming software provides advanced panel programming and user-friendly system setup

✓ Supports UARP-01 Repeater Panels

✓ 12.000 alarm, error, and warning events are supported

✓ Two separate and monitored siren outputs are supported. Without external power, connect up to 50 standard sirens. (If the UCSF-116 siren is utilized.)

✓ On the LCD display, detailed voltage and current statistics for the panel and loop can be viewed

✓ Modes of operation: night and day

✓ Supports Class A and Class B connections, allowing new devices to be quickly added to the loop through a star connection in the Project's mandatory instances.

✓ Supports variety of languages

The UAP-400 Addressable Fire Alarm Panel uses unique protocol for loop communication. It supports 4 loops, 127 devices, and up to 16 control panels can be networked. It provides sturdy and dependable solutions for operating in difficult conditions.

The UAP-400 has an LCD graphic display that enables configuring device's settings and to seamlessly interpret faulty and alarm alerts. The built-in LAN network connection of the UAP-400 enables local or remote configuration and monitoring using configuration software and Mosaic monitoring software. The UAP-200-400 Fire Alarm Panels are manufactured in accordance with the European standards and are EN54-2 and EN54-4 certified

FEATURES & BENEFITS

✓ EN 54-2 and EN 54-4 Certified

✓ User Friendly

✓ 4 loop capability is supported

✓ Each loop may support up to 127 devices and up to 508 Devices in a single panel

✓ Up to 72 zone support

✓ Cable lengths of up to 2.5 kilometers per loop

✓ The UNC-01 Network Module can connect up to 16 control panels via RS-485
✓ The network can support up to 8.128 devices and 1.152 zones (Utilizing an optional UNC-01 Network Module)

✓User-friendly interface and intuitive 240*64 large LCD digital display

✓ Customize the display with your company's logo, contact information, photos, and more

✓ Using a peer-to-peer communication network, all panels have the same level of accessibility and command transmission

✓ The software provides advanced panel programming and user-friendly system setup

✓ Supports UARP-01 Repeater Panels

✓ 12.000 alarm, error, and warning events are supported

✓ Two separate and monitored siren outputs are supported. Without external power, connect up to 50 standard sirens. (If the UCSF-116 siren is utilized.)

✓ On the LCD display, detailed voltage and current statistics for the panel and loop can be viewed

✓ Modes of operation: night & day

✓ Supports Class A and Class B connections, allowing new devices to be quickly added to the loop through a star connection in the Project's mandatory instances.

✓ Supports variety of languages
